-6AN Female Weld Bung - 6061 Aluminum

26038
  • $5.00

Only 205 left!

The Ace Race Parts brand of -6AN Female ORB AN Weld Bungs are precision CNC machined from 6061-T6 Aluminum and feature a stepped design for added weld strength and durability. Our line of Female ORB Weld Bungs are available in sizes ranging from -4AN to -20AN and are suitable in high pressure applications, like fuel systems, fuel cells, oil tanks, and other custom applications.

FEATURES

  • ORB (O-Ring Boss) Connection
  • Reusable SAE Straight Thread
  • Precision CNC Machined from 6061-T6 Aluminum
  • Capable of Handling High Pressure Applications
  • Suitable for Fuel Systems (E85 Compatible) and more!
DETAILS
  • Material Type: 6061-T6 Aluminum
  • Bung Type: Weld Bung; Female AN
  • Connection Type: O-Ring Boss (ORB)
  • Thread Type: Female - Straight Thread
DIMENSIONS
  • AN Size: -6AN
  • SAE Thread Size: 9/16"-18
  • Shoulder Diameter: 0.984"
  • Body Diameter: 0.875"
  • Height: 0.500"
